ONV industrial PoE switch applicated at Jinan-Qingdao expressway!
[Abstract]:





High-speed road HD video surveillance system features

Industrial networking, low latency, eliminates stagnation and packet loss

Support long-distance fiber transmission, no interference, reduce networking level, simplify system topology

large data and traffic video transmission

7×24h trouble-free operation

With good anti-interference and lightning protection capabilities


industrial PoE switch,PoE switch



Optical Network Video [ONV] has extensive experience in industrial Ethernet networks, We provide one-stop traffic monitoring transmission solutions.  The industrial Ethernet switches are used to set up the fiber ring network, and it has fast redundancy, high protection, and strong electromagnetic interference functions.



industrial PoE switch,PoE switch


The access layer used 14-port Gigabit managed industrial Ethernet switch with 10*10/100/1000Base-T RJ45 ports and 4*100/1000Base-X SFP slots;The aggregation layer used 28-port Gigabit managed industrial PoE switch with 24*10/100/1000Base-T RJ45 ports and 4*100/1000Base-X SFP slots...


industrial PoE switch,PoE switch




The ONV-IPS33148FM & ONV-IPS33026PFM industrial switch Gigabit RJ45 port can meet the access and transmission of a large amount of video data and accesses data such as speed camera and signal indicator to the network. The Gigabit uplink SFP port can support long-distance transmission to ensuring video data transmitted from the field to the control center.




 industrial PoE switch,PoE switch



Topology Architecture

A star topology and ring network topology networking, simple topology enhances system stability.


Switching Capacity Configuration

The access layer used managed industrial switches with downlink 10/100M RJ45 port and uplink gigabit SFP slot to set up the highest configuration switching capacity link.


industrial PoE switch,PoE switch


Link Medium

Link communication is all mixed with optic-fiber and network cable, access layer Gigabit uplink, switching capacity guarantee, no interference.


Device Configuration

The access layer used Optical Network Video [ONV] 14-port Gigabit managed industrial Ethernet switch; the Core layer used the 28-port gigabit managed industrial PoE switch.
