Gigabit 5-port wireless router-Wireless bridge/AP

Gigabit 5-port wireless router

Model： ONV-LY1800GE

The ONV-LY1800GE is a WiFi 6 gigabit router delivering dual-band speeds up to 1775Mbps—50% faster than WiFi 5 with extended range. Its dual-core processor ensures stable, high-load performance, while OFDMA and MU-MIMO enable smooth simultaneous connectivity for multiple devices. Ideal for smart homes seeking low-latency, ultra-reliable networking.

I want to make an inquiry

Overview
Technical Specification
Application
Documents
Related Products

OVERVIEW

The ONV-LY1800GE is a gigabit wireless router designed for homes of all sizes, offering ultra-high-speed connectivity. It supports next-generation WiFi 6 (802.11ax) technology on both 2.4GHz and 5GHz bands, achieving a dual-band concurrent speed of up to 1775Mbps (2.4GHz: 574Mbps, 5GHz: 1201Mbps). Compared to WiFi 5 routers, this represents a nearly 50% increase in wireless speed and a longer transmission distance. Its high-performance dual-core processor significantly enhances network load capacity, resulting in faster data forwarding and more stable long-term operation. Employing OFDMA and MU-MIMO technologies, it supports simultaneous internet access for more devices, significantly improving transmission efficiency and drastically reducing latency, making it the ideal choice for smart home networking!

FEATURE

◇ DC12V power supply

◇ 256MB RAM for large storage

◇ 1*10/100/1000Mbps adaptive WAN port

◇ 4*10/100/1000Mbps adaptive LAN ports

◇ Web browser management for easy setup

◇ Dual-core high-performance main chip processor

◇ Maximum simultaneous wireless client access of 128

◇ Dual-band WiFi 6 with a maximum wireless speed of 1775Mbps

◇ 4 external high-gain omnidirectional antennas for stronger signal

◇ Compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab standards

◇ Dual-band 2.4GHz (574Mbps) and 5GHz (1201Mbps) operating frequency bands

◇ Support WPA-PSK, WPA2-PSK, WPA-PSK+WPA2-PSK, and WPA3-SAE encryption

◇ Compliant with IEEE 802.11ax/ac/a/n 5GHz and IEEE 802.11ax/b/g/n 2.4GHz standards

PACKING LIST

Packing List	Content	Qty	Unit
	5-port Gigabit wireless router	1	PC
	User Guide	1	PC
	Warranty Card and Certificate of Conformity	1	PC

TECHNICAL SPECIFICATION

Model	ONV-LY1800GE
Hardware Specification
CPU	BCM6755
FLASH	16MB
DDR	256MB
Wired Standard	IEEE802.3,IEEE802.3u,IEEE802.3ab
Ethernet Interface	110/100/1000Mbps WAN port 410/100/1000Mbps LAN ports
Antenna	22.4GHz: 5dbi external omnidirectional antenna 25.8GHz: 5dbi external omnidirectional antenna
Button	1reset button, 1WPS
Power Supply Mode	DC12V input
Led Indicator	LED*1(SYS)
Software specification
Working Mode	WAN mode: DHCP, PPPoE, static (fixed IP) Wireless relay
Internet	LAN/WAN replacement, LAN, DHCP server, VLAN, QoS, DDNS
	VPN: PPTP client/L2TP client, static routing, network detection
	Virtual server: Port forwarding, Virtual server: DMZ
Safety	MAC address filtering, IP address filtering, domain name filtering, WPS, WiFi plans, remote management
Others	Time zone, firmware upgrade, backup/restore, manage passwords, WatchCat, scheduled reboot/restart
Diagnostic Tool	PING network continuity detection, TRACEROUTE route tracing, and NSLOOKUP
Factory Default Setting	IP address: 192.168.2.1, login username/password: admin
Wireless Specification
Wireless Standard	2.4GHz:IEEE 802.11b/g/n/ax, 5.8GHz:IEEE 802.11a/n/ac/ax
Wireless Rate	2.4GHz:574Mbps, 5.8GHz:1200Mbps
Wireless Frequency Band	2.4GHz & 5.8GHz
Wireless Encryption	WPA-PSK,WPA2-PSK,WPA-PSK/WPA2-PSK
Other Specification
Operation Temp/ Humidity	-20℃~+55℃,10%~90% RH non-condensing
Storage Temp/ Humidity	-40℃~+80℃, 5%~90% RH non-condensing
Installation	Desktop, wall mounted
Dimension (LWH)	22515237mm
Net Weight	0.45Kg
