The ONV56024F is a 10G uplink Ethernet switch independently developed by ONV. It is specifically designed for high-density terminal access and high-speed backbone interconnection scenarios. It integrates 24*10/100/1000M adaptive RJ45 ports and 2*1/2.5/10G uplink SFP+ fiber ports, forming a hybrid optical-electrical interface configuration. This allows users to overcome transmission medium limitations and freely choose copper or fiber optic cables for network deployment and expansion, achieving convenient and efficient networking connections.

Utilizing a superior high-backplane bandwidth and large-buffer switching chip solution, it significantly improves the forwarding efficiency and data processing stability for large files and high concurrency. Its intelligent traffic buffering mechanism effectively handles sudden traffic surges, preventing packet loss or delays under high load conditions. It is particularly suitable for scenarios with high real-time requirements, such as high-definition video surveillance and multimedia teaching, fundamentally alleviating problems such as video stuttering and packet loss.

A robust metal casing and excellent heat dissipation design ensure the device can withstand long-term high-load operation. Whether it's for hotel room network coverage, bank branch access, campus and factory dormitory aggregation, or office network construction for small and medium-sized enterprises, it can provide stable, high-speed gigabit to the desktop and 10G uplink capabilities at an economical cost, making it an ideal choice for building high-performance access layer networks.

FEATURE

Gigabit access, uplink 1/2.5/10G SFP+ fiber port

◇ Support non-blocking wire-speed forwarding.

◇ Support full-duplex based on IEEE 802.3x and half-duplex based on Backpressure.

◇ Support Gigabit RJ45 port and 1/2.5/10G SFP+ fiber port combination, which enables users to flexibly build networking to meet the needs of various scenarios.

Stable and reliable

◇ CE, FCC, RoHS.

◇ Self-developed power supply, high redundancy, providing a long-term and stable power output.

◇ The user-friendly panel can show the device status through the LED indicators of PWR and Link.

◇ Low power consumption, with fan, Galvanized steel housing, and excellent heat dissipation to ensure stable operation of the switch.

ORDERING INFORMATION

PACKING LIST

OPTICAL MODULE
